Proven 5th Gen Technology: Capactance Sensing & Rotary, Diaphragm = Silence & Power
Low maintenance
Plug and play
Up to 40kW / 136,000Btu/h
Ducted units; floor standing & chassis units; high wall split systems
3 year warranty
Description
SILENT+ MINI ORANGE CONDENSATE REMOVAL PUMP
The world’s No.1 Orange mini pump is now better than ever. Using our proven 5th Gen Technology, the Silent+ Mini Orange boasts sound levels as low as 16dB(A)*. So quiet it eliminates the need for additional noise or vibration dampers. Capacitance sensor technology, provides intelligent, adaptive flow rates. Quietly brilliant.
IN THE BOX:
- Silent+ Mini Orange 5th Gen pump
- Resevoir (inc. filter and lid)
- 1.5m plug and play cable**
- 1.5m clear PVC tube
- 150mm clear vent hose
- 220mm Orange inlet hose
- Drain connector kit: straight connector and rubber elbow
- Quick start guide
| Brand | ASPEN (CAT 80) |
| Dimensions | 116 x 39 x 51 |
| Max Flow | 12L/h @ 0 head |
| Max Rec. Head | 10m |
| Max Suction Lift | 1.5m |
| Tank Capacity | n/a |
| Sound Level @ 1m | 16dB(A) |
| Rated | Non continuous |
| Class | II appliance |
| Max Unit Output | 40kW (136,000Btu/h) |
| Max Water Temperature | 40o C / 104o F |
| Discharge Tube | 6mm ID |
| Inlet/Outlet | n/a |
| IP Rating | IP65 |
| Safety Switch | 5.0A Normally closed |
| Thermal Protection | Yes |
| Fully Potted | Yes |
| Self Priming | Yes |
| Power | 100-250VAC, 0.18A, 2.4W, 50/60 Hz |
| Guarantee | 1 Year |
